Heat-resistant roof-mounted

smoke extraction fan for a flue

PiroJet Fumigo

PiroJet Fumigo 160 Roof-mounted Smoke Extraction Fan

Intended use. The Fumigo 160 roof-mounted smoke extraction fan is installed on air ducts and flues with a hybrid air flow system (natural/forced circulation). When switched off, its design does not obstruct the passage of air flows, whilst when in operation, it creates a steady draught within the duct, making the unit effective for ventilation and smoke extraction. Resistant to high-temperature flue gases up to 250°C.

Areas of application.
Ventilation shafts and chimneys for extraction and smoke removal.
Individual air ducts from various ventilation systems; installation as a roof fan.
Connection of flues from boilers, stoves, etc.
Implementation of hybrid ventilation (natural/forced) instead of conventional fans.
Vertical installation; resistant to rain and snow.
Design advantages.
Unrestricted airflow when switched off.
Quiet operation; only a plume of vapour or smoke is visible above the outlet.
Self-cleaning of the impeller during operation.
Housing and components made from AISI 430 stainless steel for durability.

• Smooth speed control (the controller may be supplied separately or as part of the kit — see specifications).

Electrical connections.
Power supply: 230 V AC.
Can be connected to a generator in the event of a power cut.
Technical specifications
Type: axial fan/smoke extractor
Connection diameter: Ø130 (via adapter), 160 mm
Airflow rate: up to 360 m³/h (at 220 Pa)
Air velocity in a Ø160 duct: ≈ 5 m/s
Rotational speed: 2,100 rpm
Power consumption: up to 0.124 kW
Noise level: 55 dB(A) at 3 m
Protection class: IP44
Ambient temperature range: –25…+85 °C
Maximum flue gas temperature: up to 250 °C
Weight: ≈ 4.5 kg
Scope of supply: Speed controller (optional extra)
Manufacturer and warranty.
Manufacturer: LLC ‘LEKK INDUSTRY’
· Warranty: 12 months
· Condition: new.
