Heat-resistant roof-mounted
smoke extraction fan for a flue
PiroJet Blast 200
&
PiroJet Blast 200 Turbo
New-generation fume extractors
Roof-mounted smoke extraction fan PiroJet Blast 200
Purpose
A hybrid smoke extractor for flues and air ducts, combining natural and forced draught. When switched off, its aerodynamic shape does not impede natural draught; when switched on, it rapidly creates a stable vacuum for the reliable extraction of hot air, vapour and combustion products.
Design and materials
Housing – stainless steel; if required, it can be additionally coated with a heat-resistant and chemically resistant polymer paint (optional). Key components, including the impeller, are made from AISI 430 for corrosion resistance and stable operation at high temperatures.
Specifications (Ø200 mm version)
Airflow: up to 1,190 m³/h
Static pressure: up to 510 Pa
Operating flue gas temperature range: –25…+300 °C
Electric motor: 230 V, 0.37 kW, 3,000 rpm
Sound level: ~61 dB
Protection rating: IP54
Approximate weight: 12 kg
Manufacturer: LLC ‘LEKK INDUSTRY’
Connecting to a generator during a power cut is prohibited!
Frequency converters will fail!
Installation and operation
Vertical roof installation without additional ‘canopies’ — the unit is resistant to rain and snow. Supports connection of a speed controller for fine-tuning the draught to suit your operating conditions. The speed controller — an electronic frequency converter — is an optional extra available on request.
Applications
Fireplaces, stoves, barbecues, solid-fuel boilers; individual ventilation ducts in domestic and industrial systems; any roof-mounted hybrid extractor units where heat resistance and stable draught are required.
Advantages
Resistance to high temperatures, corrosion resistance of stainless steel components, maintenance of natural draught when switched off, compatibility with speed controllers and a neat appearance on the roof.
Purpose
A hybrid smoke extractor for flues and air ducts, combining natural and forced draught. When switched off, its aerodynamic shape does not impede natural draught; when switched on, it rapidly creates a stable vacuum for the reliable extraction of hot air, vapour and combustion products.
Design and materials
Housing – stainless steel; if required, it can be additionally coated with a heat-resistant and chemically resistant polymer paint (optional). Key components, including the impeller, are made from AISI 430 for corrosion resistance and stable operation at high temperatures.
Specifications (Ø200 mm version)
Airflow: up to 1,190 m³/h
Static pressure: up to 510 Pa
Operating flue gas temperature range: –25…+300 °C
Electric motor: 230 V, 0.37 kW, 3,000 rpm
Sound level: ~61 dB
Protection rating: IP54
Approximate weight: 12 kg
Manufacturer: LLC ‘LEKK INDUSTRY’
Connecting to a generator during a power cut is prohibited!
Frequency converters will fail!
Installation and operation
Vertical roof installation without additional ‘canopies’ — the unit is resistant to rain and snow. Supports connection of a speed controller for fine-tuning the draught to suit your operating conditions. The speed controller — an electronic frequency converter — is an optional extra available on request.
Applications
Fireplaces, stoves, barbecues, solid-fuel boilers; individual ventilation ducts in domestic and industrial systems; any roof-mounted hybrid extractor units where heat resistance and stable draught are required.
Advantages
Resistance to high temperatures, corrosion resistance of stainless steel components, maintenance of natural draught when switched off, compatibility with speed controllers and a neat appearance on the roof.
Roof-mounted smoke extraction fan PiroJet Blast 200 Turbo
Purpose
A hybrid smoke extractor for flues and air ducts, combining natural and forced draught. When switched off, its aerodynamic shape does not impede natural draught; when switched on, it rapidly creates a stable vacuum for the reliable extraction of hot air, vapour and combustion products.
Design and materials
Housing – stainless steel; if required, it can be additionally coated with a heat-resistant and chemically resistant polymer paint (optional). Key components, including the impeller, are made from AISI 430 for corrosion resistance and stable operation at high temperatures.
Specifications (Ø200 mm version)
Airflow: up to 1,910 m³/h
Static pressure: up to 1,150 Pa
Operating flue gas temperature range: –25…+300 °C
Electric motor: 230 V, 0.75 kW, 3,000 rpm
Sound level: ~61 dB
Protection rating: IP54
Approximate weight: 12 kg
Manufacturer: LLC ‘LEKK INDUSTRY’
Connecting to a generator during a power cut is prohibited!
Frequency converters will fail!
Installation and operation
Vertical roof installation without additional ‘canopies’ — the unit is resistant to rain and snow. Supports connection of a speed controller for fine-tuning the draught to suit your operating conditions. The speed controller — an electronic frequency converter — is an optional extra available on request.
Applications
Fireplaces, stoves, barbecues, solid-fuel boilers; individual ventilation ducts in domestic and industrial systems; any roof-mounted hybrid extractor units where heat resistance and stable draught are required.
Advantages
Resistance to high temperatures, corrosion resistance of stainless steel components, preservation of natural draught when switched off, compatibility with speed controllers and a neat appearance on the roof.
More powerful version
Purpose
A hybrid smoke extractor for flues and air ducts, combining natural and forced draught. When switched off, its aerodynamic shape does not impede natural draught; when switched on, it rapidly creates a stable vacuum for the reliable extraction of hot air, vapour and combustion products.
Design and materials
Housing – stainless steel; if required, it can be additionally coated with a heat-resistant and chemically resistant polymer paint (optional). Key components, including the impeller, are made from AISI 430 for corrosion resistance and stable operation at high temperatures.
Specifications (Ø200 mm version)
Airflow: up to 1,910 m³/h
Static pressure: up to 1,150 Pa
Operating flue gas temperature range: –25…+300 °C
Electric motor: 230 V, 0.75 kW, 3,000 rpm
Sound level: ~61 dB
Protection rating: IP54
Approximate weight: 12 kg
Manufacturer: LLC ‘LEKK INDUSTRY’
Connecting to a generator during a power cut is prohibited!
Frequency converters will fail!
Installation and operation
Vertical roof installation without additional ‘canopies’ — the unit is resistant to rain and snow. Supports connection of a speed controller for fine-tuning the draught to suit your operating conditions. The speed controller — an electronic frequency converter — is an optional extra available on request.
Applications
Fireplaces, stoves, barbecues, solid-fuel boilers; individual ventilation ducts in domestic and industrial systems; any roof-mounted hybrid extractor units where heat resistance and stable draught are required.
Advantages
Resistance to high temperatures, corrosion resistance of stainless steel components, preservation of natural draught when switched off, compatibility with speed controllers and a neat appearance on the roof.
More powerful version
DESCRIPTION OF FAN SPECIFICATIONS
Для ефективного всмоктування диму з мангала прийнятна швидкість в розтрубі прийнята 0,6-1,0 м/сек. Дана таблиця прораховувалася на 0,8 м/сек.
CALCULATOR
ADAPTER-COVER
Online cost estimate for a smoke extractor adapter, which can be ordered separately.
